TC-IAH161 | Honeywell | High Level Analog Imput Module

Description

• Manufacturer: Honeywell

• Product Number: TC-IAH161

• Product Type: High-Level Analog Input Module

Technical Specifications

• Number of Channels: 16

• Input Voltage Ranges:

  • ±10.25 V

  • 0 to 10.25 V

  • 0 to 5.125 V

• Input Current Range: 0 to 20.5 mA (with internal 250 Ω resistor)

• Voltage Resolution: 16 bits across each input range

• Module Publish Rate: 250 milliseconds

• Input Impedance (Voltage): > 1.0 MΩ

• Input Impedance (Current): 249 Ω nominal

• Channel Bandwidth: 20 Hz (−3 dB)

• RFI Immunity: Error < 2.0% of range at 10 V/m, 27 to 1000 MHz

• Power Dissipation: 4.1 W maximum

• Isolation Voltage (User to System): 100% tested at 2550 VDC for 1 second

• Connection Terminal Block: TC-TBCH, 36-position terminal block

• Shipping Weight: 1.5 kg
